-Door Frame Metal
Detector
(Multi Zone)
33 Zone DFMD
MODEL
"RE-MP-IX +"(9
Zone)

-Technical
Specification as per
attached
catalogue

Rubber Washer for 63mm Hydrant Valve (As per IS 5290)

Gun Metal 63mm MI x 19mm Shank Reducer

Rubber Gasket for Single Hydrant Valve

Gun Metal 63mm Hydrant Female Adaptor IS:5290

GM Orfice Plate having 100mm x 6mm

The Hydrant spanner is designed to help open and close stiff or over-tightened hydrant valves and works by locking into the spokes of the hydrant valve hand wheel.

It is manufactured from a solid steel bar and galvanized for long life. The spanner is provided with a retaining chain also.

GM Orfice Plate having 100mm x 6mm

Gunmetal 3” N.B. Orifice Plate of 3mm thickness

-CC 38 LPM 100 BAR FIRE FIGHTING SYSTEM
-13.5 HP BRIGGS & STRATTON PETROL ENGINE ( SELF START)
-FIRE FIGHTING SYSTEM WITH FOUR WHEEL TROLLEY BASE FRAME

Supply Fire Resistant Door hinge type 2 HRS fire ratings with shutter designed and manufactured
from 1.2 mm thick GI sheet duly affixed with internal stiffeners to mount accessories and
internally insulated with fire resistant insulation material and panel having overall thickness of 45
mm. The frame is fabricated from 1.6 mm thick GI sheet having single rebate having profile size
of 125 x 65 mm with necessary stiffeners and duly treated with zinc etch primer with coating of
surface and final finish of powder coating as asked in the technical specifications. The entire door
with frame is fabricated and manufactured as per BS 476 / IS 3614 to provide with integrity,
stability and thermal insulation.
1500 mm (W) X 2400 mm (H) – Double Leaf Door
Accessories:
a. S S Ball Bearing Hinges – 08 nos. (Dorma Make)
b. Panic Bar for Double Leaf – 01 no. (Dorma Make)
c. Trim Device – 01 no. (Dorma Make)
d. Door Closer – 02 nos. (Dorma Make)
e. Vision Panel (265 X 165 mm clear wired glass) – 02 nos.

Frame: 50 X 50 X 5 mm angle frame.
Shutter: Fabricated from 16 Gauge GI Sheet final finish with Powder Coating.
Glass: 250 X 450 X 6 mm thick Clear Float Glass with accessories like Hinges / Lock / Rubber Beading and Handle.

Gunmetal 137mm Suction Strainer Commercial

Strainer available in : Copper, Brass, Stainless Steel,

Outer Layer - Made out of 460 GSM Premium Aluminized Para-aramid Knitted
blend fabric tested & certified as per latest European norms EN ISO 11612:2015
& meet the class A1, A2, B2, C4, D3, E3.
Middle Layer- Neoprene quoted Fabric as vapour barier for water proof performance
- Inner Most Layer : 100% Cotton FR Fabric certified to EN ISO 11612
Suitable for proximity fire industrial radiant heat upto 1000 to 1200 deg.
- Trouser with elastic on waist & adjustable FR suspender.
- Hood with visor fireman Helmet as per IS - 2745.
- Gloves with woolen & RF lining and insulation.
- Shoes with superior quality Neoprene sole with oil skid and heat resistance.
- Size : XL with elastic pant (with belt) hence allowing one size fit all.
- Application - Foundries, Metallurgy industries, Steel Pant, Protection against the radiant heat.

Stainless steel 63mm Non Return Valve

GUN METAL 63mm MI x 137mm FRT Adaptor

Gunmetal 137mm Suction Collecting 4 way with PVC CAP With GI Chain (Body CI & Working Parts Gunmetal)

Gunmetal 137mm Suction Collecting 4 way with PVC CAP With GI Chain (Body Gunmetal & Working Parts Gunmetal)
