Specifications
| Design Parameters | |
|---|---|
| Lugs | Single Lug Type or Double Lug Type |
| Size | 63mm (2 1/2") |
| Inlet | 2 1/4" Female BSP Threaded |
| Outlet | Female Instantaneous |
| MoC (Material of Construction) | |
|---|---|
| MOC - Body/All Parts | Gunmetal |
| Rubber Washer/Ring | Natural Rubber |
| Spring | Phosphor Bronze |
| Other Working Parts | Gunmetal |
| Plunger | Brass |
| Inspection Parameters | |
|---|---|
| Test Pressure | 21 Kg/Cm2 |
| Working Pressure | 7 Kg/Cm2 |
| Finish | |
|---|---|
| Body | Buff Polished |
| Other Parts | Buff Polish |
| General | |
|---|---|
| Brand | DEVRAJ/SAFEWORLD |
| Guarantee (From Manufacturing Defect) | 1 year |
