GM 37mm Right Angle Hydrant Valve

https://www.esafeworld.com/web/image/product.template/23866/image_1920?unique=c6f1dba
(0 review)



GM 37mm Right Angle Hydrant Valve

40.44 40.44 USD 40.44 VAT Excluded

1.00 ₹ VAT Excluded

Price against Inquiry

  • Size
  • Inlet
  • Outlet
  • Flange OD
  • Lugs
  • Flange Thickness
  • Flange PCD
  • Number of Holes in Flange
  • Hole Diameter / Internal Diameter
  • Flange ID (Bore Dia)
  • MOC - Body/All Parts
  • Rubber Washer/Ring
  • Spring
  • Other Working Parts
  • Plunger
  • Chain
  • MOC Wheel
  • Spindle
  • Male Blank Cap
  • Seat Pressure
  • Test Pressure
  • Working Pressure
  • Body
  • Other Parts
  • Wheel
  • Brand
  • Guarantee (From Manufacturing Defect)

This combination does not exist.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days


Specifications

Design Parameters
Size 37 mm (1 1/2")
Inlet Flanged
Outlet Female Instantaneous
Flange OD 150mm
Lugs Pull Push Type (BR)
Flange Thickness 11mm
Flange PCD 105mm
Number of Holes in Flange 4
Hole Diameter / Internal Diameter 16mm
Flange ID (Bore Dia) 37mm
MoC (Material of Construction)
Male Blank Cap PVC Blank Cap or Gunmetal Blank Cap
MOC - Body/All Parts Gunmetal
Rubber Washer/Ring Natural Rubber
Spring Phosphor Bronze
Other Working Parts Gunmetal
Plunger Brass
Chain GI
MOC Wheel Cast Iron
Spindle Brass
Inspection Parameters
Seat Pressure 14kg/cm2
Test Pressure 21 Kg/Cm2
Working Pressure 7 Kg/Cm2
Finish
Body Powder Coated Red
Other Parts Buff Polish
Wheel ##Painted black
General
Brand DEVRAJ/SAFEWORLD
Guarantee (From Manufacturing Defect) 1 year
