Specifications
| Design Parameters | |
|---|---|
| Size | 63mm (2 1/2") |
| Inlet | Male Instantaneous (NRV) - 63mm x 3 Nos |
| Outlet | Female Round Thread - 100mm |
| MoC (Material of Construction) | |
|---|---|
| MOC - Body/All Parts | ##cast iron |
| Non Return Valve | NRV - GM |
| Other Working Parts | Gunmetal |
| Chain | GI |
| Blank Cap | Female Blank Cap - Rubber |
| Inspection Parameters | |
|---|---|
| Test Pressure | 14 kg/cm |
| Working Pressure | 7 Kg/Cm2 |
| Finish | |
|---|---|
| Body | Powder Coated Red |
| External Parts | Buff Polished |
| General | |
|---|---|
| Brand | DEVRAJ/SAFEWORLD |
| Guarantee (From Manufacturing Defect) | 1 year |
