Design Parameters
  • Size
    63mm (2 1/2")
  • Size
    50mm (2")
  • Inlet
    Flanged
  • Inlet
    Flanged
  • Outlet
    Female Instantaneous
  • Outlet
    Female Instantaneous
  • Flange OD
    185mm
  • Flange OD
    160
  • Lugs
    -
  • Lugs
    Pull Push Type (BR)
  • Flange Thickness
    12mm
  • Flange Thickness
    11mm
  • Flange PCD
    145mm
  • Flange PCD
    110mm
  • Number of Holes in Flange
    4
  • Number of Holes in Flange
    4
  • Hole Diameter / Internal Diameter
    -
  • Hole Diameter / Internal Diameter
    16mm
  • Flange ID (Bore Dia)
    63mm (2 1/2")
  • Flange ID (Bore Dia)
    50mm (2")
MoC (Material of Construction)
  • MOC - Body/All Parts
    Cast Iron
  • MOC - Body/All Parts
    Gunmetal
  • Outlet Adaptor
    -
  • Outlet Adaptor
    Single Pull Type Lug Adaptor
  • Rubber Washer/Ring
    -
  • Rubber Washer/Ring
    Natural Rubber
  • Spring
    -
  • Spring
    Brass
  • Other Working Parts
    Stainless Steel
  • Other Working Parts
    Gunmetal
  • Plunger
    -
  • Plunger
    Brass
  • Chain
    GI
  • Chain
    GI
  • MOC Wheel
    Cast Iron
  • MOC Wheel
    Cast Iron
  • Spindle
    Stainless Steel
  • Spindle
    Brass
  • Male Blank Cap
    PVC Blank Cap
  • Male Blank Cap
    PVC Blank Cap
Inspection Parameters
  • Seat Pressure
    -
  • Seat Pressure
    14kg/cm2
  • Test Pressure
    14 kg/cm2
  • Test Pressure
    14 kg/cm
  • Working Pressure
    7 Kg/Cm2
  • Working Pressure
    7 Kg/Cm2
Finish
  • Body
    Painted Red
  • Body
    Powder Coated Red
  • Other Parts
    Buff Polished
  • Other Parts
    Buff Polished
  • Wheel
    Painted Black
  • Wheel
    Painted Black
General
  • Brand
    DEVRAJ/SAFEWORLD
  • Brand
    DEVRAJ/SAFEWORLD
  • Guarantee (From Manufacturing Defect)
    1 year
  • Guarantee (From Manufacturing Defect)
    1 year
