Specifications
Design Parameters | |
---|---|
Design Standard (General Reference) | IS 15683:2018 |
Charged Weight | 125 Kg |
Capacity | 45 Kg |
Extinguishing Agent | CO2 Gas |
Total Height | 1550 mm |
Diameter | 267#10 mm |
Operating Temperature | -30 °C to +55 °C |
Functional Parameters | |
---|---|
Discharge Valve | Wheel Type |
Discharge Capacity | 95% |
Used for which Class of Fire | Class-B & Class-C & Electric fire |
Discharge Time | 20-60 sec |
Jet Range | 2 Meters |
Inspection Parameters | |
---|---|
Test Pressure | 250 bar |
Service Pressure | 60 Bar |
General | |
---|---|
Brand | KANEX |
Uncategorized | |
---|---|
Approved | None or ISI Marked & EN3 Approved |
