Specifications
Design Parameters | |
---|---|
Pressure Rating | PN 16 |
Isolation Valves Size | 50mm |
Valve Design | BS EN 593 |
Dimension | BS EN 593 |
MoC (Material of Construction) | |
---|---|
MOC - Body/All Parts | Body - Cast Iron |
MoC - Disc | SG Iron Coated With Nylon |
Body Lining | Black Nitrile |
Bearing | Acetal |
Functional Parameters | |
---|---|
Operation | Level (SG Iron / Steel) / Gearbox (Gease filled for life) - With Out Greasing Nipple |
Inspection Parameters | |
---|---|
Test Pressure | 14 kg/cm2 |
Max. Working Pressure | 16 BAR |
Max. Design Temp. | 90 c |
General | |
---|---|
Brand | AUDCO |
