CI 150MM 4 WAY FIRE BRIGADE INLET VALVE (Devraj)

https://www.esafeworld.com/web/image/product.template/24126/image_1920?unique=56fc6a8
(0 review)


CI 150mm 4 Way Fire Brigade Inlet Valve with GM NRV and PVC Female Blank Cap & Chain

0.00 0.0 USD 0.00 VAT Excluded

1.00 ₹ VAT Excluded

Price against Inquiry

  • Inlet
  • Outlet
  • Flange OD
  • Flange Thickness
  • Flange PCD
  • Number of Holes in Flange
  • Hole Diameter / Internal Diameter
  • Flange ID (Bore Dia)
  • MOC - Body/All Parts
  • Non Return Valve
  • Chain
  • Blank Cap
  • Test Pressure
  • Working Pressure
  • Body
  • Body
  • External Parts
  • Brand
  • Guarantee (From Manufacturing Defect)
  • Male Connection

This combination does not exist.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days


Specifications

Design Parameters
Inlet Male Instantaneous
Outlet 144 mm NB Flanged
Flange OD 285 mm
Flange Thickness 14mm
Flange PCD 240 mm
Number of Holes in Flange 8
Hole Diameter / Internal Diameter 23 mm
Flange ID (Bore Dia) 144 mm
MoC (Material of Construction)
Non Return Valve NRV - Gunmetal or NRV - SS or NRV-AL or NRV-Brass
Blank Cap Without Female Blank Cap or Female Blank Cap - PVC or Female Blank Cap - Rubber
MOC - Body/All Parts Cast Iron
Chain GI
Inspection Parameters
Test Pressure 21 Kg/Cm2
Working Pressure 7kg / cm2
Finish
Body CI or SG iron Body
Body Powder Coated Red
External Parts Buff Polished
General
Male Connection With Valve or Without Valve
Brand DEVRAJ/SAFEWORLD
Guarantee (From Manufacturing Defect) 1 year
