Specifications
| Design Parameters | |
|---|---|
| K Factor | 5.6(80) |
| Functional Parameters | |
|---|---|
| Temperature Rating | 175 Deg F(79 Deg C) |
| Uncategorized | |
|---|---|
| Response Type | Standard |
| Orientation | Pendant |
| End Connection | 1/2" NPT |
| Glass Bulb Size | 5mm |
| Coverage Area | 12 Sq. M |
| Frame | Brass UNS-28000 |
| Deflector | Brass UNS-28000 |
| Bulb | Glass with Glycerin Solution |
| Seal Washer | Belleville Washer Coated on both sides with teflon tape |
| Seal | Brass UNS-28000 |
| Load Screw | Brass UNS-28000 |
| Minimum Working Pressure | 7psi (0.5 bar) |
| Maximum Working Pressure | 175psi(12 bar) |
| Factory Hydrotest Pressure | 500psi(35 bar) |
| Approved | UL Listed |
