Specifications
| Design Parameters | |
|---|---|
| Size | 100mm (4") |
| Inlet | 63mm (2.5") Male Instantaneous |
| Outlet | 100mm (4") Male Round Thread |
| Inlet (Suction) | 100mm (4") Male Round Thread |
| MoC (Material of Construction) | |
|---|---|
| MOC - Body/All Parts | Aluminium |
| Handle | Aluminium |
| Functional Parameters | |
|---|---|
| Discharge Capacity | 400 gpm at 5 kgf/cm2 inlet pressure |
| Inspection Parameters | |
|---|---|
| Test Pressure | 14 kg/cm2 |
| Working Pressure | 7 Kg/Cm2 |
| Finish | |
|---|---|
| Body | Powder Coated Red or Painted Yellow |
| General | |
|---|---|
| Brand | DEVRAJ/SAFEWORLD |
| Uncategorized | |
|---|---|
| MOC - Male | Aluminium or SS 304 |
