Specifications
| Design Parameters | |
|---|---|
| Detector Part No | 55000-400/420 |
| Base Part No | 45681-210 |
| Weight | Detectore: 105g & Detector in Base - 157g |
| Operating Temperature | 20 C to 70 C |
| Dimension | (Diameter X Height) Detector: 100 X 42mm Detector in Base: 100 X 50mm |
| MoC (Material of Construction) | |
|---|---|
| MOC - Body/All Parts | Polycarbonate |
| Material | Detector House: White Polycarbonate V-0 rated to UL 94, Terminals- Nickel Plated SS |
| Inspection Parameters | |
|---|---|
| Detector Type | Point type heat detector for fire detection and fire alarm systems for buildings |
| Detector Principle | Linear approximation over temperature range 25 deg to 90 deg |
| Sensor | Single NTC Thermistor |
| Supply Voltage | 17 to 9 Volts dc |
| Modulation Voltage at Detector | 5 to 9 Volts peak to peak |
| storage Temperature | 30 C to 80 C |
| Finish | |
|---|---|
| Body | Powder Coated White |
| General | |
|---|---|
| Brand | APOLLO |
| Power Requirement | |
|---|---|
| Power | Power-up Surge Current : 1mA |
