Specifications
Design Parameters | |
---|---|
Extinguishing Agent | MAP 50% or MAP 90% |
Design Standard (General Reference) | IS 15683 |
Charged Weight | 6.6 Kg |
Capacity | 4 Kg |
Total Height | 490 mm |
Diameter | 140 mm |
Functional Parameters | |
---|---|
Fire Rating | 2A :21B |
Used for which Class of Fire | Class-A, Class-B, Class-C & Electric Fire |
Discharge Time | 18 sec |
Jet Range | 3 Meter |
Inspection Parameters | |
---|---|
Test Pressure | 35 Bar |
Service Pressure | 15 Bar |
General | |
---|---|
Brand | KANEX |
ISI Marked? | Yes |
Guarantee (From Manufacturing Defect) | 1 year |
Uncategorized | |
---|---|
Approved | None or ISI Marked & EN3 Approved |
