SS 63mm Jumbo Curtain Branch

High Pressure Fog-Gun

Made out of light weight Al. Alloy extrusions, hard
anodize, jet-spray pattern, shut-off valve with flow control
handle, flush with out shut-off, capable to discharge 600
LPM jet & spray, 35 Mtr Jet throw at 7 kg/cm2, twist
operation for Jet & Spray, 63mm male inst. inlet, As per
NFPA 1964.

Made of extruded all. Alloy hard anodized for
resistance to corrosion and wear. Select "O" metic mode
provides variable flow rates 115-225-360 and 475 lpm at 7
kg/cm2, and flush without shutting down. Spinning teeth
ring form water curtain for cooling and operators
protection from heat. Ball valve operated flow control
lever for shutting off. Inlet with 63mm male inlet
conforming to IS:903, Piston grip for greater contro

Pistol grip handle type nozzle, made out of light
weight Al. Alloy extrusion, hard anodize, selectable jet &
spray flow pattern from 360-475-600-750 and 900 LPM
and 45 Mtr maximum throw at 7 kg/cm2 pressure,
shut-off valve with flow control valve, Spinning teeth ring
generate < 120 deg Spray pattern, provision for flush
without shutting down, twist operation for jet-spray,
63mm male Inst. inlet as per IS:903, Confirming NFPA
1964.

Instantaneous Male Inlet - Stainless Steel Conforming to Grade 1 or 4 of IS : 3444 : 1999
Deflector Plate : SS 304 , Thickness Mimimum 5 mm
Washer : IS 937
The Curtain range angle should be 160 -180 degree
The operating Pressure should be 5 to 12 kg (f) / Cm2

The nozzle shall be designed to provide a constant pressure of 100 PSI over the flow range between 70 – 200 GPM. The nozzle shall be able to allow for Straight Stream to Wide Fog patterns.
The nozzle shall have arrangements to flush without shutting down the flow. The nozzle shall be built from Hard Anodized Aluminium Alloy for excellent corrosion protection.
The nozzle shall have a pistol type grip which should provide excellent grip of the nozzle for fire fighters wearing gloves or using it bare handed. The shall have a Delrin / Non Metallic Ball Valve type mechanism for flow control.
The nozzle shall have a protective bumper at the top along with a Nylon Type teeth ring. The inlet of the nozzle shall be 63 mm British Standard Type Male Inst. Connection and shall have an inlet strainer of Stainless Steel to restrict the debris entering the nozzle flow stream.
The nozzle shall have laser engraved brand name, serial number, model number and QR Code from the OEM. The nozzle shall meet NFPA 1964 Standards and shall be CE certified to EN15182. The weight of the nozzle shall be less than 3 Kgs.

GM 63mm Screwed Tripple Nozzle

Gunmetal 50mm Branch Pipe with Nozzle

Gunmetal 50mm Male Diffuser (Navy Type)

GM 63mm Nunan Type Branch

Gunmetal 37mm Branch Pipe with Nozzle

SELECT-O-FLOW NOZZLE

ALUMINIUM/GUNMETAL COMBO, MALE INSTANTANEOUS INLET

50mm Branch Pipe with Nozzle ( Pipe Copper & Nozzle & Male Gunmetal )

25mm Male Instantaneous, Aluminium
Flow - 250 LPM
