Specificaties
| Design Parameters | |
|---|---|
| Weight | 100g |
| Height | 53mm installed in Base |
| Diameter | 103mm |
| Functional Parameters | |
|---|---|
| Operating Voltage Range | 9 to 33VDC Volts Non-polarized |
| Standby Current | ≤55μA@24VDC |
| Maximum Alarm Current (LED on) | ≤50mA@24VDC |
| Operating Temperature Range | 10°C to 50°C |
| Temperature Alarm Sensitivity | 57°C (135°F) |
| General | |
|---|---|
| Brand | Agni |
| Model No. | QS951-2L |
| Type | 2 Wire/24VDC |
